ARES is dedicated to cover underground infrastructures in answer to the last requirements in modern aviation


Why you need to contact Soval export?

  • Non-return device automatically locks
  • Available with several features integrated
  • Automatic closure by elastic beam «Pushed-Slammed»


ARES range is available with several features integrated : selflocking by means of ductile iron spring bar ‘Pushed & Slammed’, hinged and spring assisted. Made of spheroidal cast iron, ARES is available from D400 up to E600 according to EN 124-2 and third party certified with TÜV Sud.

Other feature : cable-pass areas through breakable plates directly integrated into the hatch design.

In option : other lock systems, custom badging and removable badging area, technical coating, fall safety equipment integrated.

  • Safety non-return device : a the opening, non-return device automatically locks the cover and prevents the cover from being accidentally closed. A locking pin in option adds an extra level of safety. Easy closing & effortless by only rising the device. Automatic closure by elastic beam «pushed – slammed».

Identification finition & customization : on request :

  • 1 badging area for customization of 450 x 250 mm by casting on the cover or with an insert plate made of powder-coated cast iron (color of your choice).
  • 2 badging areas are available for customization of 180 x 40 mm with stainless steel plates.


  • Cover & Frame : Spheroidal Cast Iron. EN-GJS-500-7. Water Based Black Paint.
  • Accessories : Stainless steel / cast iron.
  • Gasket : EPDM monobloc.
