BLUE data logger

Description

Autonomous, communicating and connected, with an integrated pressure sensor, the BLUE data logger enables continuous and remote diagnosis and monitoring of key sectorisation data: pressures, flows, metering and regulation control.

The upgradeable LOG BLUE features an interchangeable cellular communication card for secure data transmission to the customer’s supervision system. Its Plug & Play installation, user-friendly maintenance and compact design make it easy to sectorise and provide a high level of responsiveness.

Advantages of the product :

• Remote supervision.
• Optimised design.
• Simplified installation & configuration.
• Scalable system with easy maintenance.

Specifications

• 500,000 data logger, energy autonomous.
• 2 pulse counting inputs up to 100 Hz (ready for 4 digital inputs).
• 1 x 4-20mA input.
• 1 Modbus RS485 input.
• 1 open collector output.
• Option with integrated 0-25 bar absolute pressure sensor (NSF/ANSI 61/372 drinking water certification in accordance with MH60087).
• Wireless setting and data collection via radio.
• 2G/4G communication option (LTE-M – NB-IoT).
• IP68 sealing.
• 3.6V 34Ah battery.
• W 116 x H 224 x D 52.5 mm.
• 700g (including internal pressure sensor, battery and communication card).
